Industrial BX Cable & Copper Wire Stripping Machine
*This machine is in stock and ready to ship please call to confirm voltage.
--This design is protected by the US and foreign granted and pending utility and design patents.
Tired of losing money at the scrap yard because you don't have the time or energy to manually remove the Aluminum and Steel jacket from your BX Cables? Struggling to find a machine that can automatically remove these jackets? Look no more CopperMine's Model 520 can process BX cables, copper and aluminum wires; solid or stranded, romex, and burial cables.
--Can process Aluminum & Steel BX Cables
--Equipped with an automatic copper wire stripping machine (CopperMine Model 500)
--Quick-Change Shaft makes changing dull blades quick and easy
--OSHA compliant safety guard installed with kill switch when disengaged
--Compact machine does not take up an excessive amount of space
--Easy 1-person operation
--Great for a one-man shop operation or a large scale operation
--1 Year Warranty (Excludes blades and belts)
NOTE: This item ships by scheduled freight shipment, which will arrive in one to two weeks, depending on your location. Shipping is free within the lower 48 states. Please contact us prior to making your purchase.
+ Good for wires from 22 AWG solid* /18 AWG stranded to cables 4-1/2” in diameter
+ Power requirement: 3-Phase 208VAC 60Hz 15A or (Optional: Single-Phase 240VAC 60Hz 30A)
+ Motor: 208 -240VAC, 60Hz, 5.5HP, 3-Phase or (Optional: 240VAC, 60Hz, 5.5HP, Single-Phase)
+ Weight: 780 Lbs
+ Dimensions: 50” x 20” x 53”
+ Total channels: 15
+ Adjustable Speed: Lets you set the optimum speed based on wire condition
+ Adjustable Tension works with different insulation, soft or hard
+ Double-Cut Mechanism gets the copper out in just one pass
+ Stripping speed: from 60 to 300 fpm
+ Stick blades: 2 installed on driving gears
+ Circular blades: 14 installed on front and back shafts
+ Shipping Pallet Dimensions: 64 L x 32 W x 60 H
+ Shipping Weight: 1100 Lbs
* The above range of wire gauges are for typical wire products. Due to the variety of wire structures actual range may vary.
Try it for 30 days and if it does not meet your expectations, just return it for a full refund of the purchasing price, no questions asked.
One Year Warranty (Standard):
CopperMine Tools warrants to the original purchaser that for a period of one year from date of purchase, all parts and components, excluding blades and belts, of the product are free from defects in materials workmanship.
For more info about our 5 YEAR WARRANTY Contact us!
Need Financing? No problem we offer hassle-free financing options available!
